Flat Twin Cable (FLRY)

Flat Twin Cable (FLRY)



Flat Twin Thin Wall Cable

Description:- All multicore thin wall insulation cables are made up of cores which are manufactured to ISO 6722 : 2002 (Class B) 105ºC with plain copper conductors over sheathed with PVC

Individual Core Colours:- Red & Black

Temperature Range: -15ºC to +70ºC

Part Number Description CSA
(mm		 Stranding O.D
(mm)		 Current Rating
(Amps)		 Reel Sizes
(m)
FTT050-BRB-30 Thin Wall Flat Twin 0.50mm Black - Red & Black Inner 30m 2 x 0.50 16 x 0.2 5.5 x 3.5 11 30
FTT050-BRB-100 Thin Wall Flat Twin 0.50mm Black - Red & Black Inner 100m 2 x 0.50 16 x 0.2 5.5 x 3.5 11 100
FTT050-BRB-500 Thin Wall Flat Twin 0.50mm Black - Red & Black Inner 500m 2 x 0.50 16 x 0.2 5.5 x 3.5 11 500
FTT100-BRB-30 Thin Wall Flat Twin 1.0mm Black - Red & Black Inner 30m 2 x 1.0 32 x 0.2 5.5 x 3.5 16.5 30
FTT100-BRB-100 Thin Wall Flat Twin 1.0mm Black - Red & Black Inner 100m 2 x 1.0 32 x 0.2 5.5 x 3.5 16.5 100
FTT150-BRB-30 Thin Wall Flat Twin 1.5mm Black - Red & Black Inner 30m 2 x 1.5 21 x 0.3 6.6 x 3.8 21.0 30
FTT150-BRB-100 Thin Wall Flat Twin 1.5mm Black - Red & Black Inner 100m 2 x 1.5 21x 0.3 6.6 x 3.8 21.0 100
FTT200-BRB-30 Thin Wall Flat Twin 2.0mm Black - Red & Black Inner 30m 2 x 2.0 28 x 0.3 6.6 x 3.8 25.0 30
FTT200-BRB-100 Thin Wall Flat Twin 2.0mm Black - Red & Black Inner 100m 2 x 2.0 28 x 0.3 6.6 x 3.8 25.0 100
